EDECOA 3500W DC 24V to AC 220V 230V pure sine wave power inverter
EDECOA 3500W DC 24V to AC 220V 230V pure sine wave power inverter
EDECOA 3500W DC 24V to AC 220V 230V pure sine wave power inverter
24V to 220V 3500W power inverter
EDECOA 3500W DC 24V to AC 220V 230V pure sine wave power inverter
EDECOA 3500W DC 24V to AC 220V 230V pure sine wave power inverter

EDECOA 3500W DC 24V to AC 220V 230V pure sine wave power inverter

$289.00
Shipping calculated at checkout.
Out of stock

Product architecture

EDECOA 3500W 24VDC Pure Sine Wave System Inverter with Wired LCD Monitor

Built primarily for Off-grid Solar systems that need cleaner long-duration fit, stronger day-to-day visibility, and a more system-ready operating profile than entry-level inverter setups.

Why this inverter fits this use

A System Series inverter for Off-grid Solar applications where battery behavior, recurring loads, and day-to-day visibility matter enough to justify a more system-ready product position.

Primary use case

Designed primarily for Off-grid Solar.

Compatible use cases

Also compatible with Emergency Backup, Marine when properly configured.

Market availability

Current market: EU

Key specs summary

Product type Pure Sine Wave Inverter
Rated power 3500W
Input voltage 24VDC
Waveform Pure Sine Wave
Monitoring capability LCD System Monitor

Series position

Part of the System Series.

Designed for users who need stronger system visibility, broader everyday fit, and a more complete inverter role inside the overall setup.

Positioned above Essential Series and below Smart Control or Connected configurations in system communication depth.

Monitoring structure

Layer / Monitoring capability

LCD System Monitor

Monitoring & control module

The monitoring value here is disciplined system operation. A wired LCD monitor is especially useful once the inverter is part of a fuller battery-and-load setup, because users need clearer day-to-day visibility into runtime, operating state, and system behavior.

Key engineering features

  1. System-ready positioning for fuller RV, off-grid, or backup builds rather than only light-duty inverter use.
  2. Wired LCD monitoring gives a more deliberate operating experience for recurring loads, longer runtimes, and regular system checks.
  3. Pure Sine Wave output supports broader load compatibility in daily use when the wider system is properly configured.
  4. Better fit for Off-grid Solar installations where battery, load planning, and monitoring discipline all matter together.
  5. EU market configuration in the 3500W class.

Technical specifications

ModelDPP35 ( Sinemate 3-352D )
Continuous Power3500W
Surge Power7000W
DC Input Voltage24V
AC Output Voltage220V~240V
AC Output Frequency50Hz
AC Output WaveformPure Sine Wave
USB Output (If have)/
Waveform distortionTHD<5% (Linear load)
Efficiency (＞90% Load)＞90%
DC Input Voltage Range10.5V~15V
Input Low Voltage Alarm21V±0.5V
Input Low voltage Shutdown Voltage20V±0.5V
Input High voltageShutdownVoltage31V±0.5V
No Load Current< 0.6A
SurgePower Duration0.1S
Net Weight7.1 kg
Dimensions (L x W x H)35x24x17 cm
Battery Cable (Cross-sectional area*length)25mm²x600mm
